AH-0218

6" Fire Alarm Bell

Features

  • High efficiency low current consumption on 24VDC motorized bells.
  • Terminals will accept 2.5mm cables.
  • Simple installation via multi-fixing base plate for all types of location.
  • Fitted with two series diodes for fault monitoring.
  • Option of customized discs printed with company name and logo.
  • 12VDC bells are also available.
  • Comply to EN54-3.

Approval



Specification

AH-0218 6" Fire Alarm Bell

Model AH-0218
Dimensions  ø6'' (152mm) x 56mm (H)
Voltage 24V DC
Current  25mA
Sound Output 93dB @1M
Movement Motor, Pinion, and striker
Movement Features DC Motor, acetal gear wheel,
steel striker
Gong Steel, secured with phillips screw
Base Plate Molded black polycarbonate
Material  Steel plate
Weight About 850g
