Specification
AH-0217 Manual Call Point
| Model | AH-0217 |
| Operating Contact | 6A 125/250VAC |
| Resistance | 30MΩ |
| Ambient Temperature | -25°C~+85°C |
| Dimensions | 88mm(H) x 88mm (W) x 52mm (D) |
| Weight | About 165g |
AH-0217
Manual Call Point
Features
- CE & EN54-11 approval, type A indoor.
- Available in flush or surface mounted models.
- Plastic film on glass.
- Test key inserted from bottom.
- Suitable for the majority of conventional fire alarm system.
- Clear protection cover is also available (optional).
- Choice of red, yellow, blue or green finish also available for custom-made.
Approval
