Q06

EN Heat Detector

Characteristics

  • EN54-5 Approval.
  • The standard detector is 2-wire or 3-wire with base.
  • For 4-wire type just add one relay output module on 3-wire base. Simple and easy module placement enables wider application.
  • Dual LEDs for 360-degree visibility. Bi-color LED, Stand-by Status: Green; Alarm Status: Red.
  • Detector is made of high endurance, solid and colorfast Fire-proof plastic.
  • Non-loosening screws on base terminal for easy installation.
  • Detector has passed strict EMC test, which greatly eliminates false alarms caused by interference from nearby sources.

Approval

Specification

Q06 Conventional Heat Detector

Model Q06-2 Q06-3 Q06-4
Alarm Contact N/A   N/A 0.8A @30V DC, 0.4A @125V AC
Voltage Range 12 ~ 30V DC
Alarm Current@24V DC 470Ω 40mA 40mA 45mA
Standby Current@24V DC 470Ω under 95μA Comply to EN54-5
Thermal Setting  58℃
Ambient Temperature -10℃ ~ +55℃
Material Fire-proof plastic
Dimensions 102mm(Dia.) x 46mm(H)
Weight  115g 115g 130g
Color White

Effective Alert Area

Construction/Height Under 4M 4M ~ 8M
Fire-proof Building 90 M2 45 M2
Ordinary Building 50 M2 30 M2

Order Information

Q06-2 2-wire
Q06-3 3-wire with remote indicator output
Q06-4 4-wire with relay output
