Q01

EN Photoelectric Smoke Detector

Characteristics

  • EN54-7 Approval.
  • The standard detector is 2-wire or 3-wire with base.
  • For 4-wire type just add one relay output module on 3-wire base. Simple and easy module placement enables wider application.
  • Dual LEDs for 360-degree visibility. Bi-color LED, Stand-by Status: Green; Alarm Status: Red.
  • Detector is made of high endurance, solid and colorfast Fire-proof plastic.
  • Non-loosening screws on base terminal for easy installation.
  • Detector has passed strict EMC test, which greatly eliminates false alarms caused by interference from nearby sources.

Approval

Specification

Q01 Conventional Photoelectric Smoke Detector

Model Q01-2 Q01-3 Q01-4
Alarm Contact N/A   N/A 0.8A @30V DC, 0.4A @125V AC
Voltage Range 12 ~ 30V DC
Alarm Current@24V DC 470Ω 40mA 40mA 45mA
Standby Current@24V DC 470Ω under 75μA
Sensitivity Setting Comply to EN54
Ambient Temperature -10 ~ +55
Material Fire-proof plastic
Dimensions 102mm(Dia.) x 48mm(H)
Weight  130g  130g  145g
Color White

Effective Alert Area

Building Height Area Covered
Under 4M 150 M2
4 ~ 20M 75 M2

Order Information

Q01-2 2-wire
Q01-3 3-wire with remote indicator output
Q01-4 4-wire with relay output
