Vivid32

Conventional Fire Alarm Control Panel

Characteristics

  • Model range from 1 to 32 zones.
  • AC power supply has passed EMI (Electromagnetic Interference).
  • Each zone has a separate disable function.
  • Double sets of sounder outputs.
  • Long-term or temporary silencing feature.
  • Microprocessor-base design.
  • Zonal sounder circuit with supervision.
  • LCD (24x2 lines) for events display and store capacity up to 255 events.
  • Fire Relay Output contacts and Fault Relay Output contacts.
  • Switch membrane provides longer service and is waterproof, dust resistant and easy to clean.
  • Optional individual zone indicators.

Approval

Specification

Vivid32 Conventional Fire Alarm Control Panel

Model Vivid 32
Power 220V AC, 50/60Hz  *Others also available
Battery Capacity 1~16 zone : 24V / 4 Ah
17 ~ 32 zone : 24V / 7Ah
Max. Output Current 2A @24V DC
# of heat detectors connected No limit  *Except electronic-type
# of smoke detectors connected 30/zone  *Horing Lih manufactured
Max. No. of Bells @25mA 40 per sounder circuit
End of Line Resistor 4.7kΩ    *One per zone
Material 1.2mm steel plate
Dimensions (H x W x D) mm 350 x 350 x 100
400 x 350 x 125 (with zone indicator)
Optional Features Individual zone indicator
