AH-0817

Resettable Manual Call Point

Features

  • CE & EN54-11 approval, type A outdoor.
  • Red LED with current limiting resistor.
  • Three different resistance selectable (240,470,680 ohm).
  • Choice of red, yellow, blue or green finish also available for custom-made.
  • Clear protection cover is also available (optional).

Approval

Specification

AH-0817 Resettable Manual Call Point

Model AH-0817
Operating Contact 6A 125/250VAC
Resistance 30MΩ
Ambient Temperature  -25°C~+85°C
Dimensions  87.5mm(H) x 87.5mm (W) x 54mm (D)
Weight About 145g
