AH-03127-BS

Electronic Sounder and Beacon

General

This electronic sounder is designed for use with fire alarm systems, security systems and industrial signaling systems. Combined sounder and beacon provides and audio-visual warning with is suitable for places where high sound output and visual indication is required.

Characteristics

  • EN54-3 Approval Type B Sonder Beacon
  • 32 signal tones selectable by Dip switch.
  • High  efficiency lens for maximum light output.
  • High sound output with low current consumption.
  • Volume Control as standard.
  • Two sets of IN and OUT terminals,easy for installation.

Approval

EN 54-3

Specification

AH-03127-BS Electronic Sounder and Beacon

Model AH-03127-BS
Voltage 24V DC
Current @24V DC (MAX) 40mA
Sound Oupput @ 24V DC  MAX. 106 db(A) at 1 meter
Volume Control 0 to -20dB adjustment
Ingress Protection IP44
Ambient Temperature    -25°C ~ +80°C
Material  Fire-proof plastic
Dimensions  92.5mm(Dia.) x 110mm(H)
Weight 278g

Order Information

AH-03127-S Electronic Sounder
AH-03127-BS Electronic Sounder and Beacon
